Hi ECF members, In this review i take a look at the Supbox Sevo 70W Box Kit from SXK. The SXK Supbox Sevo 70W Box Kit was supplied for the purpose of this review by Linky from Sacowin.
SXK Supbox Kit （SEVO-70 Chipset ） – SAC
Introduction
SXK are best known as one of the best cloners and for that very reason divide opinion in the vaping world. Here though we have a product of their own design which is interesting to say the least. Many Billet Box (a device SXK have cloned) lovers like the whole idea of versatility being able to use different RBA bridges and coil adaptors and the Supbox which i assume is short for Super box takes this idea of versatility to a whole new level.
The Supbox comes in this version i have received (with Sevo-70 chipset) and also a Pro version featuring the DNA60 chipset. The device is essentially a side by side which allows not just the Billet / Bantam Box fitting Supbox Pod tank which is compatible with Smok RPM coils but also the Uni Tank, Boro Tank or other tanks which are compatible with the Billet or Bantam box to fit which also means being compatible with almost all available bridges.
The versatility doesn't stop there as the Supbox also comes with a 510 connector allowing standard tanks up to 24mm in diameter to be fitted as well as being able to be used with either an 18650 or 18350 battery which gets rid of the tube giving the device quite a different look!
___________________________________________________________________
In The Box
Contents:
1 x SXK Supbox (pre-installed Supbox Pod Tank and Sleeve)
1 x USB Charging Cable
2 x Coils(0.6Ω/1.1Ω)
1 x User Manual
1 x Outer Sleeve for Atomizer
1 x 510 Plate
___________________________________________________________________
Aesthetics and Ergonomics
The Supbox came in sturdy cardboard box packaging and on opening we can see the Supbox minus drip-tip displayed and a large box of Accessories to the side. The device comes pre-installed with the Supbox Pod Tank and Cage which gives it a better look and also where the Pod Tank is concerned keeps it secured. When using the device with a standard tank it can be used without a top cage but one with a slanted and more rounded front is also supplied if you like the look. I received the Black Yellow version which is a Black device with Yellow top cages but also available is an all Black affair and Black with Red cages. The base, battery tube and cap, fire button (found on the front), side plaque and some protection edging to the Pod Tank Cage are Stainless Steel while the main construction including cages is thick ABS.
At 146g it's about the same weight as an average single battery device once the battery is installed so with the added weight of a battery it's a quite heavy device but it just feels solid. The device is curved and narrower at the spine with raised bands which adds extra grip, ergonomically it's best with the spine in the palm and using as a finger firer as to accommodate the width of boro tanks etc it's much wider at it's front. The overall form factor is basically a side by side device and moving to the stainless steel bottom we have the screen and navigational buttons within an indented section which sit flush. On one side we have a metal plaque with "Supbox" printed and beneath a micro USB port.
___________________________________________________________________
SupBox Specs and Features:
Main Features:
1. 5ml Cartridge, compatible with more than 90% of original accessories of Billet Box Pod Kit
2. Supbox pod tank compatible with SMOK RPM Coils
3. Compatible with more than 95% RTA\RDA\RDTA(less than 24 diameter) on the market
4. 5 different forms: Pod Mode, Tank/RDA Mode, Universal Mode, 18650 Mode, 18350 Mode
5. Single 18650/18350 battery, output power 1-70W, three output modes: VW/TC/By Pass
Parameter:
Construction material ABS + Stainless Steel
Size: 53 x 31 x 96mm
Weight: 146g
Chipset: Sevo 70w
Capacity: 5ml
Resistance range 0.8-3ohm
Resistance: 0.6/1.1Ω
Screen: 0.96 "
Single 18650/18350 battery
Modes: Mode: VW / Mech (Bypass) / TC (NI-TI-SS)
Colour: Full Black, Black Yellow, Red Black
___________________________________________________________________
What You Receive?
You receive the Supbox device pre-installed with the Supbox Pod Tank, installed cage and 510 drip-tip base screwed in place. You also get a 510 drip-tip, cage section for a standard tank and raised 510 plate. The Supbox Pod Tank has an 0.6ohm mesh coil pre-installed, also included is a 1.1ohm mesh coil, finally you get spare o-rings and a micro USB cable. (Note: you also receive the Uni-Tank with the Pro version).
Some random photos:
___________________________________________________________________
Modes Of Operation
The marketing shows the device to have 5 modes of operation or set-ups which isn't the case out the box with the DNA60 Pro version having 4 and the Sevo-70 having 3 but the potential is there.
First we have Pod Mode which is the use of the pre-installed Pod Mod Tank which is compatible with Smok RPM coils. Next we have Tank Mode which after removing the contact plate it gives us a 510 connector for tall tanks or you can screw in the raised 510 plate for more standard height tanks, this mode is for when using the supplied cage limiting tanks to 24mm. Next is Universal Mode which is when using the Uni Tank which 90% of available bridges will fit but the Uni Tank only comes with the DNA60 Pro version. Next is 18650 mode which is Tank Mode but without the cage which both gives a different look and increases the maximum size tank to 26mm. Finally we have 18350 mode for low wattage MTL vapers making the device smaller but the 18350 tube isn't included with either versions so will be a separate purchase.
___________________________________________________________________
Compatibility And What Else Is Available
As well as the Supbox Pod Tank which is compatible with RPM coils and the Uni Tank which isn't included with the Sevo-70 version but can be bought for just $7.20, any tank that fits inside the Billet Box Rev4 or Bantam Box will fit including the Bantam Pod Tank and All in one products like the Vapesnail.
Also as mentioned there will be an 18350 tube available and sets of the cages in different colours which i have already seen available at $10.50. Finally there are also other 18650 tubes available in different designs so the device can be customised to give it a different look!
___________________________________________________________________
Using Boro & Pod Tanks
To fit any Billet or Bantam Box Tank you just hold the Tank in position and lower the top cage that fits nicely to the shape of the Tank keeping it in position even though the set-up at this stage isn't secured. Screwing the battery cap on tightens down the cage and then screwing the drip-tip base just like with a Billet Box secures the Tank in position, just make sure the drip-tip base is secured tight so you don't have the ohms reading jumping around!
Picured: Supbox Pod Tank, Vapesnail, Bantam Pod Tank and Bantam Pod Tank with own 510!
___________________________________________________________________
Using Standard Tanks
First you need to unscrew the contact plate which is easier if you start loosening it with the use of needle nose tweezers placed in two of 4 available tiny holes, then it can be finished with your fingers, likewise when fitting back in place screw in finger tight then give it an extra turn with tweezers.
This now reveals a standard 510 connection and very tall tanks can be screwed straight in but standard size tanks will need the raised 510 plate fitting in place first. If using a tank 24mm in diameter or less you can fit the cage which like the Pod Tank cage gets secured in place by screwing the battery cap in position.
___________________________________________________________________
Fitting The Battery
The installed battery tube accommodates an 18650 battery. We have a battery cap to the top of the tube which needs unscrewing to allow the battery to be dropped in place. On the underside of the cap negative is clearly labelled and when the cap is screwed back in place it also secures the top cage (if you are using it). The threading is slightly crunchy but it screws on and off easy enough so overall very happy. The battery tube does unscrew from the device so as mentioned before a tube with a different design (separate purchase) can be fitted or when available a smaller tube to accommodate an 18350 but this would need using without the cage fitted.
___________________________________________________________________
Display
The Display is bright and very much Old School just giving the most important information. Top left we have the resistance then underneath the voltage (this is wattage when using TC), finally bottom left we have a battery status bar.
The top right area of the screen is where you will find the wattage or temperature depending which mode you are in and underneath to the left is the mode and bottom right your puffs.
___________________________________________________________________
Navigating The Supbox Sevo-70
The device is the usual 5 clicks of the fire button to turn on and 5 clicks to turn off and once on up and down together locks and unlocks the navigational buttons but the device will still fire.
To choose the mode is 3 quick clicks of the fire button which allows you to scroll through Mech (Bypass), Watts, Ni, Ti and SS, fire selects. There is also a little menu which is down and fire to enter, this gives the options to reset puffs or set a puff limit, flip the screen, enter the curves feature or turn the screen off, to turn the screen back on you need to press down and fire again to re-enter the menu.
When in TC pressing fire quickly twice allows you to use the navigational buttons to set wattage and up and fire together allows you to manually enter a TCR value.
It's a really nice user-interface but the wattage adjusts from 1w to 70w in 0.1 increments which can take time, i would prefer 5w to 20w in 0.1 increments and then switching to 1w increments up to 70w.
___________________________________________________________________
Charging
The Supbox supports on-board charging and firmware upgrades via the micro USB port using the supplied cable, a con that it's not Type C and i can't find mentioned anywhere including the manual what the charge rate actually is!
___________________________________________________________________
My Thoughts!
What a great idea, a side by side device that can also accommodate Billet Box type tanks and therefore use Billet Box Bridges. The only real issue i have is the obvious that the screen and navigational buttons are on the base as it's not ideal to have to turn the device upside down. It's just a common issue with a lot of these side by side devices because the PCB can only fit at the bottom but at least it's been implemented well and a great job has been done to get the buttons sitting absolutely flush. Also i wish the Uni tank was included with this version as well as the Pro but at least i have seen it for only $7.20 and those that have a BB Tank already are sorted.
I don't have a Billet Box but i do have the Bantam Box and Bantam Revision as well as a few bridges and the Vapesnail so i have had a hoot messing around with this. I have used the supplied Supbox Pod Tank, Bantam Pod Tank, Vapesnail and a couple of RTA's and it's been thoroughly enjoyably.
The device has a high build quality and feels like it will take some knocks, i also think people who have considered trying a Billet Box but have been put off by the price might be tempted to go this route. The device although not super ergonomic isn't particularly uncomfortable to hold but it must be pointed out it is heavy for a single battery device.
I like the fact different colour cages and different design battery tubes can be purchased and the fact an 18350 tube will also be available. The cage does limit the device to 24mm tanks but it can be used without the cage to go up to 26mm which covers the vast majority of tanks.
The Sevo chipset i have used in some Ultroner products and it's an high performing efficient chip. It fires without any delay hitting set wattage instantly and never misses a beat while giving good value for your mAh's. The user interface is very easy to navigate but is feature rich including Bypass, TC and curves.
Finally Smok RPM coils being compatible with the Supbox Pod Tank is another big pro as they are readily available and there is an extensive range to cover most peoples wattage preferences! Well i will sign off now and go and have another play, thumbs up SXK!!!
___________________________________________________________________
Likes
Very good build quality
Solid durable device
Sevo-70 high performance chipset
Efficient-good battery life comparable
DNA60 Pro version also available
Includes Supbox Pod Tank
Can use own drip tip with all fitted BB tanks
Can use all Rev4 Billet Box compatible tanks
Can use Billet Box bridges
Can use Bantam Box Tanks
Included 510 plate
Can use standard tanks with or without cage
Up to 26mm tanks compatible (24mm with cage)
2 coils included (used 1.1ohm coil gave really good flavour and medium MTL draw)
Different coloured cages and different design battery tubes available
Can be used in 18350 mode (tube a separate purchase)
RPM coils compatible
Supports on-board charging and firmware upgrades
Cons
Screen and navigational buttons on base
Wish Uni Tank was included with this version
18350 battery tube will be a separate purchase
Adjusts in 0.1w increments (con for me)
Heavy device
Not Type C and charge rate not given
I would once again like to thank Linky from Sacowin for supplying the Supbox Sevo 70W Box Kit for the purpose of this review, thanks for reading and stay safe!
