I am trying to compare a battery with a max discharge rate of 1.5C to a battery with a max discharge rate of 8.5 amps. I have searched for a conversion table and can't find one. How do you compare these values? If you are not going to reply with something directly related to my question in the form of useful information move along and don't bother posting a reply. Thanks.
Conversion Question
- Thread starter punchy187
- Start date
- th_trl_thread_readers 0
- Status
In general terms, the capacity of a cell/battery is the amount of charge available expressed in ampere-hours (Ah). An ampere is the unit of measurement used for electrical current and is defined as a coulomb of charge passing through an electrical conductor in one second. The capacity of a cell or battery is related to the quantity of active materials in it, and the amount of electrolyte and the surface area of the plates. The capacity of a battery/cell is measured by discharging at a constant current until it reaches its terminal voltage (usually about 1.75 volts). This is usually done at a constant temperature, under standard conditions of 25C (77F). The capacity is calculated by multiplying the discharge current value by the time required to reach terminal voltage.
The most common term used to describe a battery's ability to deliver current is its rated capacity. Manufacturers frequently specify the rated capacity of their batteries in ampere-hours at a specific discharge rate. For example, this means that a lead-acid battery rated for 200 Ah (for a 10-hour rate) will deliver 20 amperes of current for 10 hours under standard temperature conditions (25C or 77F). Alternatively, a discharge rate may be specified by its charge rate or C-rate, which is expressed as a multiple of the rated capacity of the cell or battery. For example, a battery may have a rating of 200 Ah at a C/10 discharge rate. The discharge rate is determined by the equation below:
C/10 rate (amperes) = 200Ah / 10 h = 20 Amperes
Battery capacity varies with the discharge rate. The higher the discharge rate, the lower the cell capacity. Lower discharge rates result in higher capacity. Manufacturer's literature on batteries will normally specify several discharge rates (in amperes) along with the associated discharge time (in hours). The capacity of the battery for each of these various discharge rates can be calculated as discussed above.
The rated capacity for lead-acid batteries is usually specified at the 8-, 10-, or 20-hour rates (C/8, C/10, C/20). UPS batteries are rated at 8-hour capacities and telecommunications batteries are rated at 10-hour capacities.
The most common term used to describe a battery's ability to deliver current is its rated capacity. Manufacturers frequently specify the rated capacity of their batteries in ampere-hours at a specific discharge rate. For example, this means that a lead-acid battery rated for 200 Ah (for a 10-hour rate) will deliver 20 amperes of current for 10 hours under standard temperature conditions (25C or 77F). Alternatively, a discharge rate may be specified by its charge rate or C-rate, which is expressed as a multiple of the rated capacity of the cell or battery. For example, a battery may have a rating of 200 Ah at a C/10 discharge rate. The discharge rate is determined by the equation below:
C/10 rate (amperes) = 200Ah / 10 h = 20 Amperes
Battery capacity varies with the discharge rate. The higher the discharge rate, the lower the cell capacity. Lower discharge rates result in higher capacity. Manufacturer's literature on batteries will normally specify several discharge rates (in amperes) along with the associated discharge time (in hours). The capacity of the battery for each of these various discharge rates can be calculated as discussed above.
The rated capacity for lead-acid batteries is usually specified at the 8-, 10-, or 20-hour rates (C/8, C/10, C/20). UPS batteries are rated at 8-hour capacities and telecommunications batteries are rated at 10-hour capacities.
Last edited:
To get a very general idea just multiply the 'C' rating times the mAh of the cell. A 900mAh 14500 x 1.5C = 1350mA (1.35A) discharge rating.
Let's get real here and talk about the cells we actually use. 1.75V terminal voltage?
Correct me if I'm wrong, but I think we covered this one already: http://www.e-cigarette-forum.com/forum/battery-mods/285509-question.html
Yea, I forgot. My bad. Thanks for the detailed reply though by Yelsew Skraps and an assist by WillyB. The battery that had the 1.5C max discharge rate was the one that threw me off and it was 2600mAh so 1.5C x 2600mAh = 3900mA (3.9A) max discharge rate. I'll take 8.5A! Titties!
