    lost vape Grus 100W mod 18650/20700/21700

    The volcanic lost vape Team does not stop! He wants to offer a full range of different devices to his passionate customers. The latest devices released in chronological order (BTB, Hybrid, Thelema and now Grus) all have in common a great constructive care, quality materials and the proprietary "Quest" chipset.

    The noble family grows! What will be the next juicy Lost Vape novelty to use the Quest chip? A dual-battery 18650 Mod or a new Bottom-feeder Mod?

    But now let's take care of the latest arrival, the Grus!

    Enjoy the reading.



    The packaging shows on the front side the image of the new Mod Grus, the brand logo, the wording "Quest" to indicate the name of the proprietary chipset used, some main features in the form of an icon and finally the name of the Mod and the maximum reachable power are indicated.



    On the back are shown; the content, the warnings, the social links of the brand, the indication on the color of the sample, security check, logos & brands.



    Side view of the package:



    The standard package includes:
    1 × Grus 100W Mod
    1 x 18650 Adapter
    1 × USB Type-C Cable
    1 × Warranty Card
    1 × User Manual



    Technical parameters and characteristics:
    - Body material: Zinc alloy
    - Dimensions: 94.6x40.5x30.5mm
    - Weight: 180g
    - Atomizer base: 30mm
    - 0.96 inch color TFT screen
    - Operating modes: VW, TC (NI200, SS, TI)
    - Battery: single 21700/20700/18650 (not included)
    - Battery voltage: 3.0V-4.2V
    - Output voltage: 0.8V-7V.
    - Power range: 5-100W
    - Current range: 0.3A-30A.
    - Temperature range: 200 ° F-600 ° F / 100 ° C -300 ° C
    - Supported Resistance Range: 0.1O-5.0Ω
    - Type-C charging.
    - Multiple protections





    Nine Colors Available:

    Wood Series:
    SS / Zebra Wood
    Black / Walnut wood
    Gunmetal / Walnut wood

    Universal Series:
    Black / Marine
    Gunmetal / Disconcerting
    SS / Jungle

    Carbon Fiber Series:
    Black / Carbon Fiber
    Gunmetal / Carbon Fiber
    SS / carbon fiber



    Lost Vape Grus 100W how it's made:

    It would be easy to describe the appearance of the Grus and reduce it to a simple rectangle; in reality its surfaces are a set of convexities, curves, bevels, grooves and flattened areas. There are no edges, its lively lines are always connected to each other in a sweet and functional way ensuring great ergonomics and tactile pleasure during the vape, moreover the Grus is stable and safe resting on the table.

    The frame is built entirely of zinc alloy, the stainless steel parts are; the 510 base, the support base and the battery compartment cap. The plastic parts concern the front panel which contains the display and the control keys.

    With so many metal parts the weight of the Grus rises up to 180g which are not few! However, even with a 21700 cell inserted and with the tank full of liquid screwed on, its portability remains very good and not at all tiring, thanks to a form factor guessed in the smallest details.



    The side view showcases the lively design of the Grus with the high color density acrylic insert in the center, this sample is part of the color choice category called "universal series" by Lost Vape. In the structure of the Grus it is easy to distinguish the areas of the steel frame from those in zinc alloy, the latter are painted the others are not. The writing "Grus" heads high on the side profile of the 510 cup, on the other side the writing is that of the Brand (Lost Vape).



    Frenkyou

    Ultra Member
    ECF Veteran
  • Apr 26, 2019
    2,066
    2,187
    56
    italy
    www.svapo.it


    The 0.96 "TFT screen is an integral part of a frame that also houses the fire button, the Mode button and the Up / Down adjustment buttons. The screen has 6 background colors, the visibility of the fonts in some occasions is not exactly optimal , all the information useful for vaping are shown except the reading of the Volts in the VW configuration.



    The slightly rounded surfaces of both narrow sides favor the grip on the mod.



    The steel cup is fixed to the Mod via two torx screws, the thread is a classic 510, the contact pin is floating, atomizers with a diameter of up to 30mm can be used without protrusions.





    The particular shape of the support base gives great stability to the Grus, on this surface there are three vent holes for the cell, the C E mark, the disposal logo and the words "Designed and Manufactured by Lost Vape Ltd" are shown. Also on this surface we find four torx screws and the cap (with handle) to access the compartment / battery.



    The Grus can use different types of cells (18650-20700-21700) for the smallest 18650 an adapter is available in the kit.



    How the Grus Mod 100W works:

    - To turn on / off the device, five clicks on the fire button are required in less than two seconds.
    - Sleep mode is automatically activated after 10s of inactivity.
    - To lock / unlock the wattage press the Up / Mode buttons simultaneously.
    - The wattage with the mod unlocked is activated with the Up / Down keys with an increase and decrease of 0.1W at a time from 5 to 100W.
    - The voltage with the mod unlocked is activated with the Up / Down keys with an increase and decrease of 0.1V at a time from 1 to 7W.
    - To enter the menu with Mod unlocked, lightly press the Mode key, the current mode lights up red, press the Up / Down keys to choose between the modes (VW, VV, TC-SS, TC-NI, TC-Ti) , then confirm the selected mode by pressing and holding the Mode key.
    - The TC SS / TI / NI mode has a value that can be set by pressing the Up / Down keys between 100 ° -300 ° C and 200 ° -600 ° F, confirm with the Mode key.
    - To delete the puff number, press the Down / Mode keys simultaneously.
    - To change one of the six screen colors, press and hold the Mode button for two seconds.
    - No Pass-Through the device warns on the screen that it is not allowed to vape while charging for safety reason.
    - Low battery the device warns on the screen that the battery charge level is low.
    - Check atomizer the device warns on the screen that it does not detect the atomizer.
    - Short circuit the device warns on the screen that the resistive value is less than 0.1Ω.
    - Too hot, when the device reaches a board temperature above 80 °, it stops and restores below 60 °.
    - Over 10s, the device locks for safety when 10s of continuous delivery are reached.



    In addition to an accurate temperature control setting menu, the Grus adopts a Type-C USB port, during recharging the cell graph is animated, when charging is complete it simply stops and the display goes into stand-by.

    The Grus has the important "Pass Trough" protection that prevents involuntary activations or vaping while reloading the Mod.

    Personally, I always recommend recharging all devices with external batteries using a specific charger; for safety reasons, greater longevity of the circuit and cells.



    HighLights Grus Mod 100W by Lost Vape:

    Pros:
    - Aesthetically beautiful with quality finishes.
    - Refined and ergonomic design.
    - Compact in width.
    - Construction materials.
    - Battery cap with sliding thread.
    - Easy to navigate chipset with convenient additional Mode button.
    - Instant power delivery.
    - Good battery management.
    - Power supply 18650-20700-21700.
    - 0.96 inch TFT color screen with 6 colors.
    - Support SS / TI / NI in temperature control mode.
    - USB-C Fast charging
    - Pass through for safety while charging
    - Possibility of hosting atomizers up to 30mm in diameter.

    Tips:
    - Volts not shown on VW screen.

    Thanks to Lost Vape for making this kit available to me for the review: Grus Mod – Lost Vape



    Letitia

    Citrus Junkie
    Supporting Member
    ECF Veteran
    Apr 2, 2017
    25,880
    137,033
    West Frankfort, IL
    Cmon Sourcemore! I want my Grus
    Yes, yes we do! With sourcemore as soon as you see what you've ordered in the 24h list shoot them a polite inquiry asking when they expect the product to be in stock and you'll get a shipping notice within a couple days.
