My stealth mod for work "The Tape Measure"

[Big Fran]

Here is a mod I made for work. I call it "The Tape Measure". LOL They told us at work since they are smoke free that we were not allowed to vape either. A few of us still do but I wanted a more stealth device then my Provari.

It is a VV single boosted 18650 battery mod with a hinged tank mount inside. It vapes great!!! It even has a belt clip. LOL

Here are the pics...



[Java_Az]

Very nice Mod. I really like the PCB the booster is installed in. The guy that designed that must be awesome. lol. For sure doesn't look like a vaporizer should fool the management no problems



[Big Fran]

Very nice Mod. I really like the PCB the booster is installed in. The guy that designed that must be awesome. lol. For sure doesn't look like a vaporizer should fool the management no problems

I got the circuit board out of a small 14500 box mod I had got from a friend. I wish I knew who made the board. I'd love to get a few more to make mods for my friends at work. LOL



[Java_Az]

Not sure who made that board but i was the one who designed it. I will have a look around i might have some left over ones around here somewhere i could send you. If you know how to make PCB or want to try here is the thread that has the files and parts list for it
http://www.e-cigarette-forum.com/forum/modding-forum/212725-ptn04050cad-laser-toner-transfer-pcb-7.html

Here is a PDF that can be used with the Toner transfer method View attachment TiboosterRev0122.pdf



[Big Fran]

That is the same board. Even the same letters and numbers on it. I don't know how to make circuit boards. I had a hard time putting a little mad vapes 5 volt regulated kit together. I am good a soldering but real small stuff I'm bad at. LOL

I only had to solder the wires to the board after taking it out on the little mod box it was in.



[ianlm]

awesome stealth mod. love it.



[Digital-Dragon]

Sweet mod Fran. So stealth... Great job. Does the tank lower so the drip tip is all theway inside?



[Big Fran]

Sweet mod Fran. So stealth.. and it looks like the tape measure still works... Great job. Does the tank lower so the drip tip is all the way inside?

Thanks for the kind words.

The tape does not work. I just cut the end off and glued it in place. The tank does not go down. It just swings out for changing. I could just remove the drip tip. LOL



[punchy187]

I am boggled by how you get everything wired up without shorts. I don't see any soldered connections even though I am sure there are some. What are you using to cover the connections?? Rubber, plastic, melted around the connections??? Kick ... mod though!



[Big Fran]

I just used shrink wrap over the joints. What you see on the 510 connector and button is epoxy used to hold them in place.

I am boggled by how you get everything wired up without shorts. I don't see any soldered connections even though I am sure there are some. What are you using to cover the connections?? Rubber, plastic, melted around the connections??? Kick ... mod though!



[zoiDman]

Great Mod.

What Red Blooded American Male Isn't Going to Want One?



[Semiretired]

You got my vote for ingenuity...



[punchy187]

@Java_Az
If you got some of those boards extra send me a couple What exactly do they do...lol?



[aziffel]

luv it!....



[punchy187]

I just used shrink wrap over the joints. What you see on the 510 connector and button is epoxy used to hold them in place.

Whats the blue stuff here? Epoxy? Also where did you get the battery holder? Or did you make it?



[bossplaya29]

freakin sweeeeet!



[Big Fran]

View attachment 85791 View attachment 85792

Whats the blue stuff here? Epoxy? Also where did you get the battery holder? Or did you make it?

The blue is shrink tube. I got the 18650 battery holder from ebay.



[springfieldarms]

That's it! I am getting started on one tomorrow at work haha



[kidbeaster]

Ah...but how does it measure up? sorry...I had to say it.


That is the coolest mod to date!!! AWESOME!!!



[inganeer]

That is a work of art. Thanks for sharing.
