The Nivel Chip

[6pointprime]

Boosting one 3.7v battery with next features:
- Variable voltage. Boosts from 3.0 to 6.0 volts with 0.1v step;
- Variable wattage. Masures your Ohms and gives the voltage needed. Regulated from 5 to 14 Watts;
- Boot loader, gives a possibility to update firmware online, so not needed to buy “next version” mods.
- 3.5 Amps limit;
- Ohm-meter;
- Second menu for “few clicks” fast up and down swithcing;
- Short circuit protrction;
- On\off switch;
- Battery monitoring;
- Thermal monitoring;
- 16 seconds cutoff;
- Reverse barrery protection(with indication);
- Inhails per hour suppresser(if you’d like to use it);
- Worktime counter(allows you to find the best battery);
- Can be used with any charger\passthrough slot;
- 7 gradations of brightness for display and button;
- Proudly made in Russia.

Nivel chip « Vapeporn



[ChrispyCritter]

Looks cool too bad it looks like they won't be selling the chip itself for modders...



[6pointprime]

Looks cool too bad it looks like they won't be selling the chip itself for modders...

I do not know if they will or will not sell the chip to modders. I would guess that they will.



[ChrispyCritter]

I do not know if they will or will not sell the chip to modders. I would guess that they will.

Oh maybe..I thought that was a supplier site and they were showing off a chip they were going to use in there mods..it would be nice to be able to buy a chip with all those options and a voltage display like that to build your own mod with..well depending on price.



[Retriever]

Interesting device. Hope it makes it over here.



[carlton]

That's nice. Real nice. Small and clean.



[Butters78]

Approves



[Sissylala]

Hrm, the only source for this that I can find is VapePorn.



[ChrispyCritter]

Hrm, the only source for this that I can find is VapePorn.

Yeah I guess it's a wait and see if it comes out..I searched also and couldn't find much info..I suspect next time you see this chip it will be in a device if it isn't from one already..would be nice to be able to buy one.



[mc0676]

Варивольт/вариватт «Nivel» (плата) ― SvoёMesto



[ChrispyCritter]

Варивольт/вариватт «Nivel» (плата) ― SvoёMesto

Nice..I converted quickly to dollars and it's around $75..if that's correct that costs too much..if it was around $20-30 I could see using one.



[expat007]

Yikes, 2690 Rubles, or about $91.65 shipped to the U.S. from Russia, with a 2-4 week lead time. Give it a few months and you'll be able to get a Chinese clone for $35.



[ChrispyCritter]

Yikes, 2690 Rubles, or about $91.65 shipped to the U.S. from Russia, with a 2-4 week lead time. Give it a few months and you'll be able to get a Chinese clone for $35.

Yeah $35 would be on the high side of reasonable and would consider that price..hopefully we will see them with different brands and lots of vendors carrying them then they would get less expensive



[expat007]

Wow, go take a look at that site. Be sure to click the "English" icon on the upper left side. Unbelievable is all I can say. You have to be an engineer to figure out what the heck you'd want to buy or what all that stuff is. They use that chip in the VV/VW "Samovar" and it looks like it has a learning curve from hell. Not to mention the 200 different tank and atomizer options. I gather it's all rebuildable and their tanks and attys can be used on 510 devices. Typically, in Russian style, it's all massively overbuilt and industrial looking. The "Samovar" looks like it probably weighs 5 pounds. They have a lot of pictures of their tanks mounted on LTs and Provaris. But god, if you wanted to order a kit from the place, you'd have to take a 3 day seminar to figure out what to buy. Either that, or just spend 5 grand and get everything they have. They've got a lot of dumbing down to do if they expect any business from the U.S., that's for sure. I guess they don't. The videos are interesting, even though they're in Russian, especially the one on the VV/VW mod. That chip does a lot. I can see why it's not cheap. It would be pretty cool to have a VV and a VW in the same device. I think you can pay your bills and monitor your heart rate with it too. LOL!



[gorman]

Isn't 14W maximum a bit anemic?



[6pointprime]

Isn't 14W maximum a bit anemic?

The Darwin maxes out at 12.8 watts.....



[Nomoreash]

Isn't 14W maximum a bit anemic?

Not at all, especially for a booster chip using 1 battery. The Kick has a 10 watt limit.



[tsbrewers]

being electronics illiterate, what would give longer run time, this and two batteries running in parallel, or two batteries in series and a drop down regulator?



[6pointprime]

being electronics illiterate, what would give longer run time, this and two batteries running in parallel, or two batteries in series and a drop down regulator?

Two batteries in parallel. Check this out:

Serial and Parallel Battery Configurations and Information



[billakosgr]

I have take one of thid chip and i think it's awsome looking so tiny only 19mm diameter X31mm lenght and 1mm thicknes i am waiting to try it into a tube....
