GG Amadeus RDTA

Status
Not open for further replies.

qorax

ECF Guru
ECF Veteran
Verified Member
Mar 6, 2013
12,652
41,476
Brampton, Canada
www.facebook.com
Amadeus Workflow...
Q Amadeus Coil Glow.jpg

Q Amadeus Ohms.jpg

Q Amadeus Wicks.jpg


AdamAnd

Super Member
ECF Veteran
Apr 20, 2011
956
1,233
Ajax, Canada
your glass tank comes nowhere making contact your o ring on the bottom
I had a similar problem, when I took apart the tank to clean it. The O-ring on the bottom must go in the channel it cannot be loose. The channel is inset and it does take a little care to affix it properly but once it was seated properly it work great. Hope this info helps


imeothanasis

Unregistered Supplier
ECF Veteran
Feb 13, 2009
47,882
34,510
Athens, Hellas
gg-goldengreek.com
Last edited:
  • Like
Reactions: Izan

imeothanasis

Unregistered Supplier
ECF Veteran
Feb 13, 2009
47,882
34,510
Athens, Hellas
gg-goldengreek.com
Some tips to avoid any issues

1. Dont screw with tool the upper part of the tank body. Just screw it very well
2. Dont screw hard at all the refilling cap on the tank mode. Stop screwing when you feel a nice soft resistance from the internal o-ring
3. Keep posts from their lower part when you close them for mtl wire
4. If liquid control becomes hard to turn, remove one of the 3 o-rings
5. if you separate deck from the feeding base, be sure to put it back again the right way
6. When you unscrew a little the center post extension to release the posts, be sure that you unscrew it by pushing a little at the same time, so deck will stay in place
7. After you receive your unit, remove totally the o-ring from the adjustable center pin
8. If you want to change air pins in tank mode, just push and turn the glass body. If the body starts turning freely and nothing happens, pull it off from the mod, put the dripper body and unscrew a little. Then push back the glass body and unscrew until the air holes under it get exposed.
9. To remove amadeus from the mod, keep it from the lower base
10. Dont screw hard the base to the feeding base. The base will screw itself after you put amadeus on your mod
11. Put your wick in a way to totally cover the feeding holes on tank mode
12. Before you refill, close the liquid control

  • Like
Reactions: RedBaron
