Hi, today let's check out the Aspire SkyStar Revvo TC Box Mod 210W Kit with Revvo Tank sent to me from buyecigkits online shop. In this Test I will examine each of the characteristics that distinguish this item. I hope that at the end of this reading you can understand this product, and therefore decide whether to invest in it or not. As always, my opinions are free and based on my personal experience.
• Enjoy the reading.
► Aspire SkyStar Revvo TC Box Mod 210W Kit with Revvo Tank; Before starting, let's see together some special features indicated by the manufacturer:
• One step top filling system
• Revolutionary ARC Coil (Aspire Radial Coil).
• Premium flavor, big vapor clouds
• Touch screen mod
• Fast response times
► Aspire SkyStar Revvo TC Box Mod 210W Kit with Revvo Tank; Packaging:
The Skystar package is black in color; on the front it bears the writing Aspire in yellow and the name of the device in white. In the center you can see the image of this Kit. On the back there is information about the content and specifications, also there are; a barcode, a QR-Code, and the various legal logos.
► Aspire SkyStar Revvo TC Box Mod 210W Kit with Revvo Tank; Packing List:
• 1 x SkyStar Revvo TC Box Mod
• 1 x 3.6ml Revvo tank
• 2 x Coils (0.10-0.16Ω)
• 1 x Glass tube
• 10 x O-rings
• 1 x USB cable
• 2 x Warning Cards
• 1 x User Manual
• 1 x Warranty Card
• 1 x Silicone protective cap
► Aspire SkyStar Revvo TC Box Mod 210W Kit with Revvo Tank; Specifications:
• Mod dimensions: 91x50x33mm
• Tank dimensions: 24x 45mm
• power range: 5-210W
• E-liquid capacity: 3.6ml
• Battery type: Dual 18650
• Voltage range: 0.5-9.0V
• Resistance range: 0.1-0.5Ω
• Timeout adjustable from 5 to 15 seconds
• 1.3-inch OLED touchscreen
• Output Mode: VW/ VV/ BYPASS/ TC/ CPS
• Temperature control: 100-315°C/ 200-600°F
► Aspire SkyStar Revvo TC Box Mod 210W Kit with Revvo Tank; Available colours:
• Slate Blue
• Black carbon fiber
• White
• Wood grain effect
• Blue Camo
► Aspire SkyStar Revvo TC Box Mod 210W Kit with Revvo Tank; First Impressions:
Better late than never! When this kit was presented a few years ago, I remember the numerous enthusiastic reviews that spoke of great innovation especially for the Mod with its touch controls, but also for the tank with its incredible disc-shaped Arc Coils. It so happened that David (the representative of the buyecigkits online shop) contacted me kindly asking me which device I wanted to review for them. One of the first kits that I happened to see in their extensive catalog was the SkyStar with Revvo tank, and it was like a bolt from the blue! I had no doubts, this had to be mine! So I requested it from Chris immediately. After about 12 days I received the SkyStar Revvo kit in a fantastic "Black Carbon Fiber" color and I must say that handling it turned out to be even better than I imagined. Although the Mod is designed to house two batteries, it is not bulky at all, weighs little, provides a good feeling of robustness and is rather ergonomic and pleasant to handle with its soft curves. The endowment is quite rich and includes everything you need; like the hygienic cap for the tank and also two ARC coils that intrigue me so much.
The top of the Mod houses the 510 cup with spring loaded gold plated pin in the center. Revvo looks like a RDTA and has a diameter of 24mm, however on the mod it is possible to install any atomizer with a maximum diameter of 26mm without external protrusions. Like the upper part, the lower part is also made of solid mirror-polished metal. The lower base has a nice wide footprint and this allows the Mod to stand steadily.
The mirror polished metal also continues on the sides giving the Mod a remarkable structural strength. Both front/rear panels are made of good quality plastic material and are decorated in the sporty and timeless "Carbon Look" style.
The rear panel has a recess on the bottom to allow you to lift the cover to access the compartment/battery. Inside there are two slots for the 18650 cells, these slots are made of flame ......ant type plastic material and are marked with the "+" and "-" symbols for the correct insertion of the cells. There is also a convenient strap to allow you to remove the batteries easily. Internally, the cover has two very tenacious magnets that maintain a perfect closure without any movement.
► Aspire SkyStar Revvo TC Box Mod 210W Kit with Revvo Tank; touch screen:
SkyStar Mod on the front has a beautiful 1.3 "touch screen surrounded by a protective polished metal frame. The monochromatic characters are very bright and easy to read. Inside this frame and just above the screen, there is an invisible key fire. With three clicks you can hide the screen to the full advantage of energy saving. When you want to set the parameters you can click 3 times to make the information visible again. With five clicks you can lock the display and immediately after by holding down the fire button for two seconds you can turn off the mod. 5 clicks are needed to restart the mod. To enter the setting you need to swipe your finger from top to bottom twice quickly. You can scroll through the various menus and set different modes such as; power, Volt, Bypass , TC, TCR, CPS, with 3 different memory and prehit settings (soft, norm, hard).It is also possible to adjust several parameters such as; maximum single puff duration, screen brightness, clock settings. The Mod can be adjusted from 5 to 210W in 0.1W steps from 5 to 100w and in 1W steps from 100 to 210W.
► Aspire Revvo Tank:
The Aspire Revvo is a 24mm Top Air-Flow Sub-ohm Tank with a unique top-fill design that allows filling through the drip tip without having to open anything. Another interesting detail is the ARC (Aspire Radial Coil) system designed by Aspire, which makes these large disc-shaped coils similar to kitchen stoves.
In the images below you can see how this design is very similar to a common RDTA system, in fact the top cap is screwed to the tank and at the top of the tank there is the ARC coil which remains suspended and is fed by the liquid below. Inside the top cap there are two dowels that correspond to the rotation stops of the ring that regulates the flow of air. The amazing e-liquid filling system consists of a long funnel-shaped cone which is spring loaded, this allows you to fill the tank with liquid (3.6ml) by pressing the spout of the dispenser and squeezing the bottle above its. To remove the ARC (Aspire Radial Coil) you need to unscrew the cone located at the base of this funnel.
The top airflow ring has a knurled surface for better finger grip when adjusting. There are 3 air inlet slots which have a length of 10mm and a height of 3mm each. This ensures a large airflow that maximizes cloud production, and the top afc system ensures that this vaporizer is watertight.
► Aspire ARC (Aspire Radial Coil):
The Aspire Revvo Tank of this Kit comes with two different 0.10 and 0.16Ω Kanthal coils. ARC coils are flat in shape and look just like electric stove tops. The idea behind this unusual form factor is to increase the heating surface to produce more vapor and flavor.
► Aspire SkyStar Revvo TC Box Mod 210W Kit with Revvo Tank; Final conclusions:
During about two weeks of use I got a rather precise idea of these ARC Coils, they have a long life provided you keep them well lubricated, in fact when the liquid level inside the tank is low, it is advisable to tilt the mod to allow to the liquid to keep the cotton moist. The coils supplied are very similar to each other in behavior, both are quick to touch the fire and give their best with a selected power ranging from 70 to 85 watts. At the beginning when these coils are new, a "metallic" taste is perceived which decreases and disappears as you continue to use them. The flavor is average, slightly below any current production mesh coil. The large airflow combined with the large radiating surface of the ARC Coils generates an amazing production of vapor, and this is one of the best aspects of these coils. With intensive and continued use, ARC Coils tend to overheat the drip-tip especially if you keep the airflow setting below 50% of the maximum opening portion.
Aspire SkyStar Mod overall has a sleek and minimalistic look with not so numerous but still enough color selection to please your taste. The metal chassis is undoubtedly solid and the finish of the lids should be durable and able to stand the test of time. Compared to the other mods, Aspire SkyStar Revvo offers a beautiful, beautifully sharp 1.3" OLED touchscreen. Outdoor readability is not a problem and the screen is recessed into the body of the mod safe from scratches, furthermore with this arrangement the screen is also quite protected from shocks. The power button seems sturdy and of good quality, it emits a pleasant click every time it is pressed. The speed of ignition is excellent and the battery management seems to be normal. The two 18650 batteries maintain the power in constant output. The prehit curves are adjustable and can be useful when using other coils that take longer to activate. The temperature control supports all common materials and the TCR curves are easily customized thanks to the easy to use touch menu Navigation The on-screen touch menu makes it exceptionally simple to make desired changes, and the interface is highly intuitive and accessible even for beginners. I am absolutely delighted to have had the opportunity to obtain this historic kit and I think it could really intrigue a lot of people.
• I'd like to thank David from the buyecigkits online shop for providing me with the kit. You can buy Aspire SkyStar Revvo TC Box Mod Kit with Revvo Tank at the affordable price of $47.99 Link Buyecigkits
• Thank you for reading.
