Hello All
Not sure how many of you out there have a Hybris ecig Variable Voltage mod by AquaVapor.
Hybris Variable Voltage Ecig Mod - Highest Quality Mini Variable Voltage eCig Mod on the Market Designed by AquaVapor LLC
Thought I would start a thread for talking about it. What do you like, what do you not like. Any chit chat is welcome. There is a 10% off coupon on the home page of the site. Just ordered my 3rd. One thing I don't like is it comes with a Li-ion battery, I prefer IMR myself.
Let the thread begin.
Vape On
Burnie
Standard parameters
Input voltage:2.5V-5.5V with 3.7V lithium battery
Output voltage :3.0V-6.0V (Allowable error ±0.1V)
Atomizer resistance :1.0Ω-5.0Ω (Suggested Use 2Ω-3.0Ω atomizer)
Charging voltage :4.2v/ 420mA
Specification
Ultra-low quiescent current, reverse battery protection, output over-current, short circuit protection
For ultra-high efficiency buck-processing chip, more effectively regulated the output voltage stability , digital voltage LCD display
Battery voltage measurement function, low battery voltage alarm protection
Atomizer resistance measurement capability
Charge with USB charger from top thread top
Features
1. Activation button/big button ---- voltage output control , atomizer resistance check
Press the big button (activation Button) to activate the device and start vaping. release the button to to stop the atomizer activation
If press it for more than 10 seconds ,the output is automatically stopped (cut off time is 10 seconds )
Click the big button 5 times in 2 seconds to check the resistance of atomizer. Display range : 0.0~9.9Ω;atomizer
Resistance Allowable error ±0.2Ω,short circuit display 0,breaking display F1。
When the battery voltage is lower than 3.3v , device will stop working and the LCD will blink 10 times , low voltage alarm indicator
2. Button --- "-", "on/off" and Decrease Voltage button
Press it to decrease the voltage by 0.1v increments. Once the voltage reach to 3.0v ,it will circle back to 6.0v
When the LCD shuts off , press the "-" button to activate LCD, the voltage won’t decrease, press it again and the voltage decrease
Press this button for 3 seconds to turn the device on and off
3. Button--- "+" ,“battery voltage check”
Press it to increase the voltage by 0.1v increments . Once the voltage reach to 6.0v ,it will circle back to 3.0v
When the LCD shuts off , press the "+" button to activate LCD, the voltage won’t decrease, press it again and the voltage decrease .
Press the "+" button for 3 seconds , to check the battery voltage.Display range: 2.8V-4.5V,Allowable error ±0.2V .
4. Button - & +
Press the button "–" and "+" at the same time for 3 seconds ,the LCD will blink one time and current set voltage will be locked / unlocked. When the voltage is locked ,press the button – or + the LCD will illuminate but voltage can't be changed until unlocked
5. Charging The Hybris:
Connect the USB charger to top of device to charge ,the light of big activation button will blink 3 times , the LCD will display the current voltage of battery once the LCD turns off ,the battery is full charged
During charging the buttons on device will not function
You can also charge the internal 14500 battery with a compatible 14500 charger
Not sure how many of you out there have a Hybris ecig Variable Voltage mod by AquaVapor.
Hybris Variable Voltage Ecig Mod - Highest Quality Mini Variable Voltage eCig Mod on the Market Designed by AquaVapor LLC
Thought I would start a thread for talking about it. What do you like, what do you not like. Any chit chat is welcome. There is a 10% off coupon on the home page of the site. Just ordered my 3rd. One thing I don't like is it comes with a Li-ion battery, I prefer IMR myself.
Let the thread begin.
Vape On
Burnie
Standard parameters
Input voltage:2.5V-5.5V with 3.7V lithium battery
Output voltage :3.0V-6.0V (Allowable error ±0.1V)
Atomizer resistance :1.0Ω-5.0Ω (Suggested Use 2Ω-3.0Ω atomizer)
Charging voltage :4.2v/ 420mA
Specification
Ultra-low quiescent current, reverse battery protection, output over-current, short circuit protection
For ultra-high efficiency buck-processing chip, more effectively regulated the output voltage stability , digital voltage LCD display
Battery voltage measurement function, low battery voltage alarm protection
Atomizer resistance measurement capability
Charge with USB charger from top thread top
Features
1. Activation button/big button ---- voltage output control , atomizer resistance check
Press the big button (activation Button) to activate the device and start vaping. release the button to to stop the atomizer activation
If press it for more than 10 seconds ,the output is automatically stopped (cut off time is 10 seconds )
Click the big button 5 times in 2 seconds to check the resistance of atomizer. Display range : 0.0~9.9Ω;atomizer
Resistance Allowable error ±0.2Ω,short circuit display 0,breaking display F1。
When the battery voltage is lower than 3.3v , device will stop working and the LCD will blink 10 times , low voltage alarm indicator
2. Button --- "-", "on/off" and Decrease Voltage button
Press it to decrease the voltage by 0.1v increments. Once the voltage reach to 3.0v ,it will circle back to 6.0v
When the LCD shuts off , press the "-" button to activate LCD, the voltage won’t decrease, press it again and the voltage decrease
Press this button for 3 seconds to turn the device on and off
3. Button--- "+" ,“battery voltage check”
Press it to increase the voltage by 0.1v increments . Once the voltage reach to 6.0v ,it will circle back to 3.0v
When the LCD shuts off , press the "+" button to activate LCD, the voltage won’t decrease, press it again and the voltage decrease .
Press the "+" button for 3 seconds , to check the battery voltage.Display range: 2.8V-4.5V,Allowable error ±0.2V .
4. Button - & +
Press the button "–" and "+" at the same time for 3 seconds ,the LCD will blink one time and current set voltage will be locked / unlocked. When the voltage is locked ,press the button – or + the LCD will illuminate but voltage can't be changed until unlocked
5. Charging The Hybris:
Connect the USB charger to top of device to charge ,the light of big activation button will blink 3 times , the LCD will display the current voltage of battery once the LCD turns off ,the battery is full charged
During charging the buttons on device will not function
You can also charge the internal 14500 battery with a compatible 14500 charger
